Porsche 917/30 Specifications
| type | Racing Car |
| built at | Germany |
| production | 6 units |
| engine |
Air Cooled, Magnesium/Aluminum Alloy Flat-12
|
| position | Mid Longitudinal |
| aspiration | Twin Eberspacher Turbos |
| ignition | Twin Spark, Dual 12V Distributors |
| block material |
RZ5 Magnesium Alloy w/Chromal Cylinders
|
| valvetrain |
Gear Driven DOHC, 2 Valves per Cyl
|
| fuel feed |
Indirect, Mechanical Bosch Fuel Injection
|
| displacement | 5374 cc / 327.9 in³ |
| bore | 90 mm / 3.54 in |
| stroke | 70.4 mm / 2.77 in |
| compression | 6.5:1 |
| power | 809.1 kw / 1085 bhp @ 7800 rpm |
| specific output | 201.9 bhp per litre |
| bhp/weight | 1356.25 bhp per tonne |
| torque | 1098.2 nm / 810 ft lbs @ 6400 rpm |
| body / frame | Body over Tubular Frame |
| driven wheels | RWD w/LSD |
| front brakes | Vented Discs |
| rear brakes | Vented Discs |
| steering | Rack & Pinion |
| f suspension | Double Wishbones |
| r suspension | Double Wishbones |
| curb weight | 800 kg / 1764 lbs |
| wheelbase | 2500 mm / 98.4 in |
| front track | 1670 mm / 65.7 in |
| rear track | 1654 mm / 65.1 in |
| length | 4562 mm / 179.6 in |
| width | 2085 mm / 82.1 in |
| height | 1080 mm / 42.5 in |
| transmission | Type 920 Four-Speed Manual |
| top speed | ~386.2 kph / 240 mph |
| 0 – 60 mph | ~2.1 seconds |
| fuel capacity | 400 litres or 105.60 gal. |
