Porsche 917/30 – Specifications & Performance

Technical Specifications

Porsche 917/30 Can-Am

Porsche 917/30 Specifications

type Racing Car
built at Germany
production 6 units
engine
Air Cooled, Magnesium/Aluminum Alloy Flat-12
position Mid Longitudinal
aspiration Twin Eberspacher Turbos
ignition Twin Spark, Dual 12V Distributors
block material
RZ5 Magnesium Alloy w/Chromal Cylinders
valvetrain
Gear Driven DOHC, 2 Valves per Cyl
fuel feed
Indirect, Mechanical Bosch Fuel Injection
displacement 5374 cc / 327.9 in³
bore 90 mm / 3.54 in
stroke 70.4 mm / 2.77 in
compression 6.5:1
power 809.1 kw / 1085 bhp @ 7800 rpm
specific output 201.9 bhp per litre
bhp/weight 1356.25 bhp per tonne
torque 1098.2 nm / 810 ft lbs @ 6400 rpm
body / frame Body over Tubular Frame
driven wheels RWD w/LSD
front brakes Vented Discs
rear brakes Vented Discs
steering Rack & Pinion
f suspension Double Wishbones
r suspension Double Wishbones
curb weight 800 kg / 1764 lbs
wheelbase 2500 mm / 98.4 in
front track 1670 mm / 65.7 in
rear track 1654 mm / 65.1 in
length 4562 mm / 179.6 in
width 2085 mm / 82.1 in
height 1080 mm / 42.5 in
transmission Type 920 Four-Speed Manual
top speed ~386.2 kph / 240 mph
0 – 60 mph ~2.1 seconds
fuel capacity 400 litres or 105.60 gal.
