Porsche 914/4 (1.8L) – Specifications & Performance

Technical Specifications

Porsche 914/4 (1.8L) Specs

1974-1975 Porsche 914 1.8L Specifications

Engine 1.8 L Flat 4
Induction Normally-aspirated
Cooling Air/oil-cooled
Pushrod-actuated overhead valves
Injection Port injection
Bore X Stroke 3.66 in/93 mm x 2.60 in/66 mm
Displacement 109.50 cu-in/1,795 cc
Horsepower 76 bhp @ 4800 rpm
Torque 100 lb-ft @ 3400 rpm
Compression Ratio 7.5:1
Tansmission 5-speed manual
Chassis Type Mid-engined, rear wheel drive
Curb Weight 2,094 lbs.
Height 48.43 in/1,230 mm
Ground Clearance 4.69 in/119 mm
Length 156.89 in/3,985 mm
Wheelbase 96.46 in/2,450 mm
Width 64.96 in/1,650 mm
Track Front 52.87 in/1,343 mm
Track Rear 54.45 in/1,383 mm
Drag Coefficient N/A
Wheel Size Front 15 x 4.5
Wheel Size Rear 15 x 4.5
Tire Size Front 155SR-15
Tire Size Rear 155SR-15
Caliper Front Floating 1-piston
Caliper Rear Floating 1-piston
Disc Type Front Solid discs
Disc Type Rear Solid discs
Disc Size Front 10.98 in/279 mm
Disc Size Rear 11.06 in/281 mm
0 To 60 Mph N/A
Top Speed 108 mph
