Porsche 911 S Targa (1967 – 1968) – Specifications & Performance

1967 – 1968 Porsche 911 S Targa 2.0 (SWB) Technical Specifications

Engine Type Flat 6
Induction
Normally-aspirated
Cooling Air/oil-cooled
Valvetrain
Single overhead camshaft
Injection Carburetion
Bore X Stroke
3.15 in/80 mm x 2.60 in/66 mm
Displacement
121.45 cu-in/1,991 cc
Horsepower
160 bhp @ 6600 rpm
Torque
132 ft lbs @ 5200 rpm
Max Rpm 7200
Compression Ratio 9.8:1
Transmission Options 5-speed manual
Chassis Type
Rear-engined, rear-wheel drive
Body / Frame Unitary Steel
Curb Weight 2,271 lbs.
Height
51.97 in/1,320 mm
Ground Clearance 5.91 in/150 mm
Length
163.90 in/4,163 mm
Wheelbase
87.05 in/2,211 mm
Width
63.39 in/1,610 mm
Track Front
53.82 in/1,367 mm
Track Rear
52.87 in/1,343 mm
Drag Coefficient 0.38
Wheel Size Front 15 x 5.5
Wheel Size Rear 15 x 5.5
Tire Size Front 165/70HR-15
Tire Size Rear 165/70HR-15
Caliper Front Fixed 2-piston
Caliper Rear Fixed 2-piston
Disc Type Front Ventilated discs
Disc Type Rear Ventilated discs
Disc Size Front
11.10 in/282 mm x 0.79 in/20 mm
Disc Size Rear
11.22 in/285 mm x 0.79 in/20 mm
0 To 60 Mph 8.1 seconds
Top Speed 141 mph
