Porsche 911 996 (1998 – 2006) – Fuses Box Diagram and Amperages List

Carrera, Carrera 4, Carrera S, Carrera 4S, Targa and Turbo

Porsche 911 996 (1997 - 2006) – Fuses Box Diagram and Amperages List

1998-2006 Porsche 911 Fuses Box Diagram and Amperages List

This fuse box information is ONLY for the following Porsche models and years:

  • 1998 to 2006 Porsche 911 (996) Carrera, 4, S, 4S, Targa and Turbo – years 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005 and 2006

Fuse Box Location

The fuse box in the Porsche 911 (996 series) is located on the doors side of the drivers footwell, under a black cover. Once the cover is removed you’ll see the fuse box.

Fuse Box Diagram

911 (996) Fuses Box Diagram and Amperages List

There are 5 rows of fuses in the fuse box diagram (A to E). Each row have 10 fuses. Fuses nomenclature is A-5, C-7, etc. The fuse list and amperage is different depending on the model year of your 996. Click below on the year of your car to jump to the fuse box list of your car.

996 MY1998 Fuses List and Amperage

A1 7.5A HIGH BEAM RIGHT
A2 7.5A HIGH BEAM LEFT
A3 7.5A SIDE MARKER LIGHT RIGHT
A4 7.5A SIDE MARKER LIGHT LEFT
A5 15A
LICENSE PLATE LIGHTS, INSTRUMENT LIGHTS
A6 25A SEAT HEATER M139/M340
A7 25A FOG LIGHT, REAR FOG LIGHT
A8 7.5A
LICENSE PLATE LIGHTS CANADA M113
A9 7.5A LOW BEAM RIGHT
A10 7.5A LOW BEAM LEFT
B1 15A
CLUSTER, TlPTRONIC, BUTTON ASR ON/OFF, DIAGNOSIS, POWER TOP
B2 7.5A RADIO, INFOSYSTEM
B3 25A TWO-TONE HORNS
B4 15A
ENGINE COMPARTMENT CLEANER FAN
B5 7.5A
BACKUP LIGHT, CU POWER TOP, CU MEMORY
B6 15A
HAZARD-WARNING LIGHT SWITCH
B7 15A
STOP LIGHT, CRUISE CONTROL
B8 15A
CU CLS ALARM, CU DME, CU TIPTRONIC M249
B9 15A CU ABS TRACTION CONTROL
B10 15A
INSTRUMENT CLUSTER DIAGNOSIS
C1 25A RELAY MFI~DI
C2 30A
RELAY IGNITION, OXYGEN SENSOR
C3 15A
CU ALARM SYSTEM, CENTRAL LOCKING SYSTEM, POWER WINOOW
C4 25A RELAY FUEL PUMP
C5
C6 25A WIPER
C7 7.5A TERM.X CONTROL WIRES
C8 30A RADIATOR FAN 2
C9 25A
HEADLIGHT CLEANING SYSTEM M288
C10 30A RADIATOR FAN 1
D1 30A POWER WINDOW
D2 30A
MIRROR, REAR WINDOW DEFOGGER
D3 30A DRIVE POWER TOP
D4 30A POWER WINDOW REAR
D5 15A CIGAR LIGHTER
D6 30A RELAY HEATER
D7 15A
HAZARD WARNING LIGHT SWITCH
D8 15A SPOILER EXTENSION
D9 15A AUDIO OPTION PACK M490
D10 7.5A
MOUNTING POINT FOR RETROFIT, WARNING MAXIMUM OF 5 A
E1 7.5A
TERM.86S, CU-CL ALARM, RADIO, CLUSTER CU INFO SYSTEM
E2 7.5A CU MEMORY M537 / M538
E3 30A
POWER SEAT, CU MEMORY SEAT LEFT M537
E4 30A
POWER SEAT, CU MEMORY SEAT RIGHT M538
E5 7.5A INFOSYSTEM M662
E6 7.5A
TERM.30 TELEPHONE/HANDY, NAVIGATION CONTROL UNIT M614IM618/M662?
E7 7.5A
AIR CONDITIONING SYSTEM M573
E8 7.5A
TERM.15 TELEPHONE/HANDY INFOSYSTEM M614 / M618 / M662?
E9 30A FDR M476
E10 30A FDR M476

996 MY1999 and MY2000 Fuses List and Amperages

A1 15A
HIGH BEAM RIGHT, HIGH BEAM CONTROL
A2 15A HIGH BEAM LEFT
A3 7.5A SIDE MARKER LIGHT RIGHT
A4 7.5A SIDE MARKER LIGHT LEFT
A5 15A
LICENSE PLATE LIGHTS, INSTRUMENT LIGHTS
A6 25A SEAT HEATER M139/M340
A7 25A FOG LIGHT, REAR FOG LIGHT
A8 7.5A
LICENSE PLATE LIGHTS CANADA M113
A9 15A LOW BEAM RIGHT
A10 15A LOW BEAM LEFT
B1 15A
CLUSTER, TlPTRONIC, BUTTON ASR PSM, DIAGNOSIS, CU POWER TOP
B2 7.5A RADIO
B3 25A TWO-TONE HORNS
B4 15A
ENGINE COMPARTMENT BLOWER
B5 7.5A
BACKUP LIGHT, CU MEMORY MIRROR ADJUSTMENT, CU POWER TOP
B6 15A
TURN SIGNALS, POWER WINDOW
B7 15A
STOP LIGHT, CRUISE CONTROL
B8 15A
CU CLS ALARM, CU ENGINE ELECTRONICS, CU TIPTRONIC M249
B9 15A CU ABS, ASR, PSM
B10 15A
INSTRUMENT CLUSTER DIAGNOSIS, HEADLIGHT VERTICAL AIM CONTROL
C1 25A ENGINE ELECTRONICS
C2 30A
IGNITION, INJECTION, OXYGEN SENSOR HEATER
C3 15A
CU CLS ALARM, POWER WINOOW, SUN ROOF, CU POWER TOP, INSIDE LIGHT
C4 25A FUEL PUMP
C5
C6 25A WIPER
C7 7.5A TERM.X CONTROL WIRES
C8 30A RADIATOR FAN RIGHT
C9 25A
HEADLIGHT CLEANING SYSTEM M288
C10 30A RADIATOR FAN LEFT
D1 30A POWER WINDOW FRONT
D2 30A
REAR WINDOW DEFOGGER, MIRROR HEATING
D3 30A
CONVERTIBLE TOP DRIVE, SUN ROOF
D4 30A
POWER WINDOW REAR CABRIO
D5 15A CIGAR LIGHTER
D6 30A
HEATER AIR CONDITIONING SYSTEM
D7 15A
HAZARD WARNING, A.TURN SIGNAL SYSTEM
D8 15A REAR SPOILER
D9 15A AUDIO OPTION PACK M490
D10 7.5A
MOUNTING POINT FOR RETROFIT, WARNING MAXIMUM OF 5 A
E1 7.5A
TERM.86S/ CU-CL ALARM/ RADIO/ CLUSTER/ DAYTIME RUNNING LIGHT/ CU INFO SYSTEM/ CU SENSOR OVERTURN
E2 7.5A CU MEMORY M537 / M538
E3 30A
POWER SEAT, CU MEMORY SEAT LEFT M537
E4 30A
POWER SEAT, CU MEMORY SEAT RIGHT M538
E5 7.5A INFOSYSTEM M662
E6 7.5A
TERM.30 TELEPHONE/HANDY, NAVIGATION, ORVR, M614IM618/M662
E7 7.5A
AIR CONDITIONING SYSTEM M573
E8 7.5A
TERM.15 TELEPHONE/HANDY INFOSYSTEM M614 / M618 / M662
E9 30A PSM M476
E10 30A PSM M476

996 MY2001 Fuses List and Amperages

A1 15A
HIGH BEAM RIGHT, HIGH BEAM CONTROL
A2 15A HIGH BEAM LEFT
A3 7.5A SIDE MARKER LIGHT RIGHT
A4 7.5A SIDE MARKER LIGHT LEFT
A5 15A
LICENSE PLATE LIGHTS, INSTRUMENT LIGHTS
A6 25A SEAT HEATER M139/M340
A7 25A FOG LIGHT, REAR FOG LIGHT
A8 7.5A
LICENSE PLATE LIGHTS CANADA M113
A9 15A LOW BEAM RIGHT
A10 15A LOW BEAM LEFT
B1 15A
CLUSTER, TlPTRONIC, BUTTON ASR PSM, DIAGNOSIS, CU POWER TOP
B2 15A
HAZARD WARNING LIGHT SWITCH
B3 25A TWO-TONE HORNS
B4 15A
ENGINE COMPARTMENT BLOWER
B5 7.5A
BACKUP LIGHT, CU MEMORY MIRROR ADJUSTMENT, CU POWER TOP
B6 15A
TURN SIGNALS, POWER WINDOW
B7 15A
STOP LIGHT, CRUISE CONTROL
B8 15A
CU CLS ALARM, CU ENGINE ELECTRONICS, CU TIPTRONIC M249
B9 15A CU ABS, ASR, PSM
B10 15A
INSTRUMENT CLUSTER DIAGNOSIS, HEADLIGHT VERTICAL AIM CONTROL
C1 25A ENGINE ELECTRONICS
C2 30A
IGNITION, INJECTION, OXYGEN SENSOR HEATER
C3 15A
CU CLS ALARM, POWER WINOOW, SUN ROOF, CU POWER TOP, INSIDE LIGHT
C4 25A FUEL PUMP
C5
C6 25A WIPER
C7 7.5A TERM.X CONTROL WIRES
C8 30A RADIATOR FAN 2
C9 25A
HEADLIGHT CLEANING SYSTEM M288
C10 30A RADIATOR FAN 1
D1 30A POWER WINDOW FRONT
D2 30A
REAR WINDOW DEFOGGER, MIRROR HEATING
D3 30A
CONVERTIBLE TOP DRIVE, SUN ROOF
D4 30A
POWER WINDOW REAR CABRIO
D5 15A CIGAR LIGHTER
D6 30A
HEATER, AIR CONDITIONING SYSTEM
D7 15A REAR SPOILER
D8 15A RADIO
D9 15A AUDIO OPTION PACK M490
D10 7.5A
MOUNTING POINT FOR RETROFIT, WARNING MAXIMUM OF 5 A
E1 7.5A
TERM.86S/ CU-CL ALARM/ RADIO/ CLUSTER/ DAYTIME RUNNING LIGHT/ CU INFO SYSTEM/ CU SENSOR OVERTURN
E2 7.5A CU MEMORY M537 / M538
E3 30A
POWER SEAT, CU MEMORY SEAT LEFT M537
E4 30A
POWER SEAT, CU MEMORY SEAT RIGHT M538
E5 7.5A INFOSYSTEM M662
E6 7.5A
TERM.30 TELEPHONE/HANDY, NAVIGATION, ORVR, M614IM618/M662
E7 7.5A
AIR CONDITIONING SYSTEM M573
E8 7.5A
TERM.15 TELEPHONE/HANDY INFOSYSTEM M614 / M618 / M662
E9 30A PSM M476
E10 30A PSM M476

996 MY2002 Fuses List and Amperages

A1 15A
HIGH BEAM RIGHT, HIGH BEAM CONTROL
A2 15A HIGH BEAM LEFT
A3 7.5A SIDE MARKER LIGHT RIGHT
A4 7.5A SIDE MARKER LIGHT LEFT
A5 15A
LICENSE PLATE LIGHTS, LOCATING LIGHT, INSTRUMENT LIGHTING
A6 25A SEAT HEATER M139/M340
A7 25A
FOG LIGHT, REAR FOG LIGHT M465/M466
A8 7.5A
LICENSE PLATE LIGHTS CANADA M113
A9 15A LOW BEAM RIGHT
A10 15A LOW BEAM LEFT
B1 15A
CLUSTER, TlPTRONIC, BUTTON ASR PSM, DIAGNOSIS, CU POWER TOP
B2 15A
HAZARD-WARNING, A.TURN-SIGNAL SYSTEM
B3 25A TWO-TONE HORNS
B4 15A
ENGINE COMPARTMENT BLOWER
B5 7.5A
BACKUP LIGHT, CU MEMORY MIRROR ADJUSTMENT, CU POWER TOP
B6 15A
TURN SIGNALS, POWER WINDOW
B7 15A
STOP LIGHT, CRUISE CONTROL M454
B8 15A
CU ALARM-CL, CU ME, CU TIPTRONIC M249
B9 15A CU ABS, PSM
B10 15A
INSTRUMENT CLUSTER DIAGNOSIS, HEADLIGHT VERTICAL AIM CONTROL
C1 25A ENGINE ELECTRICS
C2 30A
IGNITION, INJECTION, HEATER OXYGEN SENSORS
C3 15A
CU ALARM-CL, POWER WINOOW, SUN ROOF, CU POWER TOP, INSIDE LIGHT
C4 30A FUEL PUMP
C5
C6 25A WIPER
C7 7.5A TERM.X CONTROL WIRES
C8 40A RADIATOR FAN RIGHT
C9 25A
HEADLIGHT CLEANING SYSTEM M288
C10 40A RADIATOR FAN LEFT
D1 30A POWER WINDOW FRONT
D2 30A
REAR WINDOW DEFOGGER, MIRROR HEATING
D3 30A
CONVERTIBLE TOP DRIVE, SUN ROOF M650
D4 30A
POWER WINDOW REAR CABRIO
D5 15A CIGAR LIGHTER
D6 30A
HEATER, AIR CONDITIONING SYSTEM
D7 15A
REAR SPOILER COVER OPENER
D8 7.5A RADIO
D9 15A AUDIO OPTION PACK M490
D10 7.5A TELEPHONE
E1 7.5A
TERM.86S/ CU-CL ALARM/ RADIO/ CLUSTER/ DAYTIME RUNNING LIGHT/ INFO SYSTEM/ CU SENSOR OVERTURN
E2 7.5A CU MEMORY M537 / M538
E3 30A
POWER SEAT, CU MEMORY SEAT LEFT M537
E4 30A
POWER SEAT, CU MEMORY SEAT RIGHT M538
E5 7.5A INFOSYSTEM M662
E6 7.5A
TERM.30 TELEPHONE/HANDY, NAVIGATION, ORVR, M614IM618/M662
E7 7.5A
AIR CONDITIONING SYSTEM M573
E8 7.5A
TERM.15 TELEPHONE/HANDY INFOSYSTEM M614 / M618 / M662
E9 25A PSM M476
E10 15A PSM M476

996 MY2003 Fuses List and Amperages

A1 15A
HIGH BEAM RIGHT, HIGH BEAM CONTROL
A2 15A HIGH BEAM LEFT
A3 7.5A SIDE MARKER LIGHT RIGHT
A4 7.5A SIDE MARKER LIGHT LEFT
A5 15A
LICENSE PLATE LIGHTS, LOCATING LIGHT, INSTRUMENT LIGHTING
A6 25A SEAT HEATER M139/M340
A7 25A
FOG LIGHT, REAR FOG LIGHT M465/M466
A8 7.5A
LICENSE PLATE LIGHTS CANADA M113
A9 15A LOW BEAM RIGHT
A10 15A LOW BEAM LEFT
B1 15A
CLUSTER, TlPTRONIC, BUTTON ASR PSM, DIAGNOSIS, CU POWER TOP
B2 15A
HAZARD-WARNING, A.TURN-SIGNAL SYSTEM
B3 25A TWO-TONE HORNS
B4 15A
ENGINE COMPARTMENT BLOWER
B5 7.5A
BACKUP LIGHT, CU MEMORY MIRROR ADJUSTMENT, CU POWER TOP
B6 15A
TURN SIGNALS, POWER WINDOW
B7 15A
STOP LIGHT, CRUISE CONTROL M454
B8 15A
CU ALARM-CL, CU ME, CU TIPTRONIC M249
B9 15A CU ABS, PSM
B10 15A
INSTRUMENT CLUSTER DIAGNOSIS, HEADLIGHT VERTICAL AIM CONTROL
C1 25A ENGINE ELECTRICS
C2 30A
IGNITION, INJECTION, HEATER OXYGEN SENSORS
C3 15A
CU ALARM-CL, POWER WINOOW, SUN ROOF, CU POWER TOP, INSIDE LIGHT
C4 30A FUEL PUMP
C5
C6 25A WIPER
C7 7.5A TERM.X CONTROL WIRES
C8 40A RADIATOR FAN RIGHT
C9 25A
HEADLIGHT CLEANING SYSTEM M288
C10 40A RADIATOR FAN LEFT
D1 30A POWER WINDOW FRONT
D2 30A
REAR WINDOW DEFOGGER, MIRROR HEATING
D3 30A
CONVERTIBLE TOP DRIVE, SUN ROOF M650
D4 30A
POWER WINDOW REAR CABRIO
D5 15A CIGAR LIGHTER
D6 30A
HEATER, AIR CONDITIONING SYSTEM M573/M574
D7 15A
REAR SPOILER COVER OPENER
D8 7.5A RADIO
D9 15A AUDIO OPTION PACK M490
D10 7.5A TELEPHONE
E1 7.5A
TERM.86S/ CU-CL ALARM/ RADIO/ CLUSTER/ DAYTIME RUNNING LIGHT/ INFO SYSTEM/ CU SENSOR OVERTURN
E2 7.5A CU MEMORY M537 / M538
E3 30A
POWER SEAT, CU MEMORY SEAT LEFT M537
E4 30A
POWER SEAT, CU MEMORY SEAT RIGHT M538
E5 7.5A INFOSYSTEM M662
E6 7.5A
TERM.30 TELEPHONE/HANDY, NAVIGATION, ORVR, M614IM618/M662
E7 7.5A
AIR CONDITIONING SYSTEM M573
E8 7.5A
TERM.15 TELEPHONE/HANDY INFOSYSTEM M614 / M618 / M662
E9 25A PSM M476
E10 15A PSM M476

996 MY2004 Fuses List and Amperages

A1 15A
HIGH BEAM RIGHT, HIGH BEAM CONTROL
A2 15A HIGH BEAM LEFT
A3 7.5A SIDE MARKER LIGHT RIGHT
A4 7.5A SIDE MARKER LIGHT LEFT
A5 15A
LICENSE PLATE LIGHTS, LOCATING LIGHT, INSTRUMENT LIGHTING
A6 25A SEAT HEATER M139/M340
A7 25A
FOG LIGHT, REAR FOG LIGHT M465/M466
A8 7.5A
LICENSE PLATE LIGHTS CANADA M113
A9 15A LOW BEAM RIGHT
A10 15A LOW BEAM LEFT
B1 15A
CLUSTER, TlPTRONIC, BUTTON PSM PSM, DIAGNOSIS, CU POWER TOP
B2 15A
HAZARD-WARNING, A.TURN-SIGNAL SYSTEM
B3 25A TWO-TONE HORNS
B4 15A
ENGINE COMPARTMENT BLOWER
B5 7.5A
BACKUP LIGHT, CU MEMORY MIRROR ADJUSTMENT, CU POWER TOP
B6 15A
TURN SIGNALS, POWER WINDOW
B7 15A
STOP LIGHT, CRUISE CONTROL M454
B8 15A
CU ALARM-CL, CU ME, CU TIPTRONIC M249
B9 15A CU ABS, PSM
B10 15A
INSTRUMENT CLUSTER DIAGNOSIS, HEADLIGHT VERTICAL AIM CONTROL
C1 25A ENGINE ELECTRICS
C2 30A
IGNITION, INJECTION, HEATER OXYGEN SENSORS
C3 15A
CU ALARM-CL, POWER WINOOW, SUN ROOF, CU POWER TOP, INSIDE LIGHT
C4 30A FUEL PUMP
C5
C6 25A WIPER
C7 7.5A TERM.X CONTROL WIRES
C8 40A RADIATOR FAN RIGHT
C9 25A
HEADLIGHT CLEANING SYSTEM M288
C10 40A RADIATOR FAN LEFT
D1 30A POWER WINDOW FRONT
D2 30A
REAR WINDOW DEFOGGER, MIRROR HEATING
D3 30A
CONVERTIBLE TOP DRIVE, SUN ROOF M650
D4 30A
POWER WINDOW REAR CABRIO
D5 15A CIGAR LIGHTER
D6 30A
HEATER, AIR CONDITIONING SYSTEM M573/M574
D7 15A
REAR SPOILER COVER OPENER
D8 7.5A RADIO
D9 15A AUDIO OPTION PACK M490
D10 7.5A TELEPHONE
E1 7.5A
TERM.86S/ CU-CL ALARM/ RADIO/ CLUSTER/ DAYTIME RUNNING LIGHT/ INFO SYSTEM/ CU SENSOR OVERTURN
E2 7.5A CU MEMORY M537 / M538
E3 30A
POWER SEAT, CU MEMORY SEAT LEFT M537
E4 30A
POWER SEAT, CU MEMORY SEAT RIGHT M538
E5 7.5A INFOSYSTEM M662
E6 7.5A
TERM.30 TELEPHONE/HANDY, NAVIGATION, ORVR, M614IM618/M662
E7 7.5A
AIR CONDITIONING SYSTEM M573
E8 7.5A
TERM.15 TELEPHONE/HANDY INFOSYSTEM M614 / M618 / M662
E9 25A PSM M476
E10 15A PSM M476
