Porsche 906 Spyder – Specifications & Performance

Technical Specifications

Porsche 906 Spyder Specifications

Specs 906/8 Spyder “Ollon Villars”
Engine: 8-cylinder boxer engine (four-stroke)
Displacement: 1981 cc
Bore × stroke: 76.0 x 54.6 mm
Performance at 1 / min: 191 kW (260 hp) at 8800
Max. Torque at 1 / min: 210 Nm at 7100
Compression: 10.5: 1
Valve control: One overhead camshaft each , chain control
Cooling: Air cooling (fan)
Transmission: 5-speed gearbox and limited slip differential; Rear wheel drive
Brakes: Dual circuit disc brakes
Front suspension: Double wishbones with stabilizer
Rear suspension: Inclined wishbones with stabilizer and guidance through longitudinal struts
Front suspension: Coil springs with telescopic shock absorbers
Rear suspension: Coil springs with telescopic shock absorbers
Body: Plastic body with tubular space frame
Track width front / rear: 1340/1410 mm
Wheelbase : 2300 mm
Tires rim: VA: 5.25-13 on? J × 13
HA: 7.00-13 on? J × 13
Dimensions L × W × H: 3580 ×? ×? mm
Empty weight : 488 kg (1073.6 lbs)
Top speed: 162 mph (260 km / h)
