Porsche 936/76 – Specifications & Performance

Technical Specifications

Porsche 936/76 Specifications

Specs 936 Spyder (1976)
Engine: 6-cylinder boxer engine (four-stroke) + one exhaust gas turbocharger
Displacement: 2142 cc
Bore × stroke: 83.0 x 66.0 mm
Power: 520 bhp @ 8000 rpm
Torque 356 ft lbs at 6000 rpm
Compression: 6.5: 1
Valve control: One overhead camshaft with chain drive each
Cooling: Air cooling (fan)
Transmission: 5-speed gearbox, limited slip differential , rear-wheel drive
Brakes: Disc brakes (internally ventilated)
Front suspension: Wishbones with longitudinal thrust struts, anti-roll bar
Rear suspension: One lower wishbone and one upper and one lower longitudinal thrust strut
Front suspension: one progressively acting coil spring per wheel with gas pressure shock absorber
Rear suspension: one progressively acting coil spring per wheel with gas pressure shock absorber
Body: Aluminum tubular space frame with plastic body
Track width front/rear: 1580/1510 mm
Wheelbase : 2400 mm
Tires rim: VA: 265/565 × 15 on 10.5J × 15, HA: 340/600 × 15 on 15J × 15
Dimensions L × W × H: 4200 × 1980 × 1010 mm
Empty weight : 700 kg
Top speed: 350 km / h
