| Model |
911 Carrera S |
| Generation |
992.2 |
| Model Year |
2025 |
| Technical Data |
|
Engine
|
|
| Engine layout |
Rear Engine |
| Engine type |
Boxer, twin-turbo |
| Cylinders |
6 |
| Valves per cylinder |
4 |
| Construction |
Aluminum crankcase and heads |
| Fuel injection |
Direct Fuel Injection (DFI) |
| Fuel |
Premium |
| Displacement (Liters) |
3.0 l |
| Bore/Stroke (mm/mm) |
91.0 mm / 76.4 mm |
| Maximum power output @ engine speed |
473 hp @ 6500 |
| Maximum torque @ engine speed |
390 lb.-ft. @ 2200-6000 |
| Maximum engine speed |
7500 |
| Compression ratio (tolerance +/- 0.3) |
10.2 : 1 |
| Output per liter |
157 hp |
| Lubrication |
Integrated dry-sump |
| Weight to power ratio (lb/hp) |
7.2 |
| Drivetrain |
Rear-wheel drive |
Chassis & Suspension
|
|
| Body |
Monocoque lightweight body in a combination of steel, aluminum, and magnesium |
| Front Axle |
MacPherson strut with anti-roll bar |
| Rear Axle |
Aluminum multi-link with anti-roll bar |
| Steering System |
Variable ratio electromec. power steering |
| Steering Ratio |
15.0 : 1 (on-center) to 12.25 : 1 |
| Steering Ratio with rear-axle steering |
14.1 : 1 (on-center) to 12.25 : 1 |
| Turning Circle |
36.8 ft / 35.8 ft. (with rear axle steering) |
Brakes & Wheels
|
|
| Caliper type |
Aluminum monobloc fixed-caliper brake |
| Rotor material |
Steel |
| Caliper color |
Red |
| Number of pistons (front/rear) |
6 / 4 |
| Rotor diameter (front/rear) mm |
408 mm / 380 mm |
| Rotor thickness (front/rear) mm |
36 mm / 34 mm |
| Caliper type (optional PCCB system) |
Aluminum monobloc fixed-caliper brake |
| Rotor material (optional PCCB system) |
Carbon-ceramic composite |
| Caliper color (optional PCCB system) |
Yellow |
| Number of pistons (front/rear – optional PCCB system) |
10 / 4 |
| Rotor diameter (front/rear – optional PCCB system) mm |
420 mm / 410 mm |
| Rotor thickness (front/rear – optional PCCB system) mm |
40 mm / 32 mm |
| Standard wheels |
20″ / 21″ Carrera S |
| Wheels (front/rear) |
8.5J x 20″ / 11.5J x 21″ |
| Tires (front/rear) |
245/35 ZR 20 / 305/30 ZR 21 |
Transmission
|
|
| Number of gears |
8 |
| Transmission type |
8-speed dual-clutch PDK |
| Ratios |
|
| 1st |
4.89 |
| 2nd |
3.17 |
| 3rd |
2.15 |
| 4th |
1.56 |
| 5th |
1.18 |
| 6th |
0.94 |
| 7th |
0.76 |
| 8th |
0.61 |
| Reverse |
3.99 |
| Final drive ratio front axle |
N/A |
| Rear Axle Ratio / rear constant transaxle ratio |
3.39 / 0.92 |
| Clutch 1/Clutch 2 diameter (inches) |
8.7 / 6.6 inches (PDK) |
Dimensions, Aerodynamics, & Weight
|
|
| Length with standard PASM Sport Suspension (inches/mm) |
178.8 in. / 4542 mm |
| Wheelbase (inches/mm) |
96.5 in. / 2450 mm |
| Width w/ mirrors (inches/mm) |
80 in. / 2033 mm |
| Width w/o mirrors (inches/mm) |
72.9 in. / 1852 mm |
| Height with standard PASM suspension (inches/mm) |
51.3 in. / 1303 mm |
| Height with optional PASM Sport Suspensio |
50.9 in. / 1293 mm |
| Track width front (inches/mm) |
63 in. / 1601 mm |
| Track width rear (inches/mm) |
61.2 in. / 1555 mm |
| Cargo area volume (cu.-ft.) front trunk |
4.8 cu.-ft. |
| Cargo area volume (cu.-ft.) rear seats |
261 l / 9.2 cu.-ft. |
| Cargo area volume (cu.-ft.) w/o rear seat |
373 l / 13 cu.-ft. |
| Fuel tank capacity – refill volume (gal) |
16.6 |
| Optional extended range fuel tank capacity (gal) |
22.1 |
| Curb weight (lbs) |
3,424 lbs. |
| Gross Vehicle Weight (lbs) |
4,156 lbs. |
| Payload range (lbs) |
981 lbs. |
Performance
|
|
| Top track speed PDK (mph) |
191 mph |
| Acceleration 0-60 PDK (sec) |
3.3 sec. |
| Acceleration 0-60 PDK with Launch Control (sec) |
3.1 sec. |
| Quarter mile time PDK (sec) |
11.6 sec. |
| Quarter mile time PDK with Launch Control (sec) |
11.4 sec. |
Fuel Economy/Rating
|
|
| Rating |
– |
| City |
TBD |
| Highway |
TBD |
| Combined |
TBD |
