Porsche 911 (996) Engine Numbers (All Years)

911 (996) Engine Codes

Porsche 911 (996) Engine Codes

At its debut, the 996 featured the most significant change from the classic 911 series: a water-cooled engine replacing the previously air-cooled engine. Progressively stringent emissions and noise regulations, environmental concerns, a higher expectation for refinement and the need for a high-performance 4 valve per cylinder engine made the switch necessary.

Most models of the 996 generation of the Porsche 911 (excluding GT3 / GT3 RS / GT2 & Turbo models) sports car were afflicted with a vulnerability in the intermediate shaft (IMS) that drove their engines’ camshafts. Failure of the ball bearing within the IMS leads to varying degrees of engine failure. In general, after an IMS bearing failure, the engine internals could be contaminated with debris from the failure that requires the engine to be stripped and rebuilt. In severe failure modes, cam timing could be affected, leading to valve-piston impact, necessitating a rebuild or replacement of the entire engine.

In 2000, Porsche introduced the 996 Turbo, equipped with a four-wheel-drive system and a 3.6-litre, twin-turbocharged and intercooled flat-six engine generating a maximum power output of 309 kW (420 PS; 414 hp). In 2002, the standard Carrera models underwent the above-mentioned facelift. In addition, engine capacity was also increased to 3.6-litres across the range, yielding gains of 11 kW (15 PS; 15 hp) for the naturally aspirated models.

VEHICLE ENGINE TYPE MY ENGINE-NUMBERS CYLINDERS DISPLACEMENT POWER (kW) POWER (hp)
911 CARRERA M96.01 1,998 W 66W 00501>60000 6ZYL 3.4L 220 kW 299 hp
911 CARRERA M96.01 1,999 X 66X 00501>60000 6ZYL 3.4L 220 kW 299 hp
911 CARRERA +M620 C4 M96.02 1,999 X 68X 00501>60000 6ZYL 3.4L 220 kW 299 hp
911 CARRERA 2/4 M96.04 2,000 Y 66Y 00501>60000 6ZYL 3.4L 220 kW 299 hp
911 CARRERA 2/4 M96.04 2,001 1 661 00501>60000 6ZYL 3.6L 232 kW 315 hp
911 CARRERA 2/4/4S FL M96.03 2,002 2 662 00501>60000 6ZYL 3.6L 235 kW 320 hp
911 CARRERA 2/4/4S FL M96.03 2,003 3 663 00501>60000 6ZYL 3.6L 235 kW 320 hp
911 CARRERA 2/4/4S FL M96.03 2,004 4 664 00501>60000 6ZYL 3.6L 235 kW 320 hp
911 CARRERA 2/4/4S FL M96.03 2,005 5 665 00501>60000 6ZYL 3.6L 265 kW 360 hp
996 GT3 M96.76 2,000 Y 63Y 21501>23000 6ZYL 3.6L 265 kW 360 hp
996 GT3 M96.76 2,001 1 631 21501>23000 6ZYL 3.6L 265 kW 360 hp
996 GT3 M96.79 2,004 4 634 24501>26000 6ZYL 3.6L 280 kW 381 hp
996 GT3 RS M96.79 2,004 4 634 26501>27000 6ZYL 3.6L 280 kW 381 hp
996 GT3 M96.79 2,005 5 635 24501>26000 6ZYL 3.6L 280 kW 381 hp
911 TURBO M96.70 2,001 1 641 00501>60000 6ZYL 3.6L 309 kW 420 hp
911 TURBO GT2 M96.70S 2,001 1 641 00501>60000 6ZYL 3.6L 340 kW 462 hp
911 TURBO M96.70 2,002 2 642 00501>60000 6ZYL 3.6L 309 kW 420 hp
911 TURBO GT2 M96.70S 2,002 2 642 00501>60000 6ZYL 3.6L 340 kW 462 hp
911 TURBO M96.70 2,003 3 643 00501>60000 6ZYL 3.6L 309 kW 420 hp
911 TURBO GT2 M96.70S 2,003 3 643 20501>60000 6ZYL 3.6L 340 kW 462 hp
911 TURBO M96.70 2,004 4 644 00501>60000 6ZYL 3.6L 309 kW 420 hp
911 TURBO GT2 M96.70S 2,004 4 644 20501>60000 6ZYL 3.6L 340 kW 462 hp
911 TURBO IX50 KIT M96.70E 2,004 4 644 30501>40000 6ZYL 3.6L 336 kW 457 hp
911 TURBO M96.70 2,005 5 645 00501>20000 6ZYL 3.6L 309 kW 420 hp
911 TURBO GT2 M96.70S 2,005 5 645 20501>30000 6ZYL 3.6L 360 kW 489 hp
911 TURBO IX50 KIT M96.70E 2,005 5 645 30501>40000 6ZYL 3.6L 336 kW 457 hp
